Mutoh ValueJet 1638WX
- Transfer sublimation printing up to 1625 mm (63.97”)
- Staggered dual head setup with latest generation 1440 nozzle piezo heads
- Advanced print automation : Mutoh i² Intelligent Interweaving and new DropMaster technology inside
- Production speeds between 42 & 65 m²/h
- New cost-effective Mutoh universal dye sublimation inks
- Ideal for production of soft signage, apparel and gadgets
- Environmentally friendly printing – high level of operator safety
Destined for high quality volume applications, the ValueJet 1638WX wide format printer offers production speeds up to 42 m²/h at 360 x 720 dpi and 65 m²/h at 360 x360 dpi. The machine supports all typical dye sublimation transfer paper weights (from 66 g/m² to 150 g/m²).
The dual head ValueJet 1638WX printer will offer you the well-known and much appreciated ValueJet product line features and more. ValueJet 1638WX will push the boundaries of speed, quality and ease of use :
- Extreme print quality at high speeds and at amazingly high resolutions
- Unrivalled overall dot control, leading to better image definition for all speeds
- Excellent cost per print performance and durability
The ValueJet 1638WX printer incorporates a staggered dual head setup with latest generation piezo drop-on-demand variable drop print heads. Each 1440-nozzle head (8 lines of 180 nozzles) incorporates four colour sections, divided in two nozzle rows with 360 nozzles per colour.
The integrated print heads are capable of producing ink drops ranging from 5.9 pl to 45.3 pl. Bottom line, they can produce a wider range of ink dots, which are moreover jetted at a much faster speed compared to other print heads on the market. The result is faster output speeds and moreover a much better print quality at higher output speeds.
The ValueJet 1638WX printer offers you a wide range of print modes and speeds. The overview below lists the most popular ones with which impeccable printing quality can be obtained.
• Quality – 720×720 dpi: 25 m²/h
• Production – 360×720 dpi: 42 m²/h
• Speed Production – 360×360 dpi : 50 m²/h
• High Speed Production– 360×360 dpi: 65 m²/h
Maximize your Profit with Mutoh Intelligent Interweaving (i²) Print Technology
The ValueJet 1638WX incorporates Mutoh’s award-winning Intelligent Interweaving (i²) print technology, enabling a drastic reduction or even total elimination of the typical difficulties inherent to conventional digital inkjet printing, such as horizontal banding, step mismatch banding and the visible effects of missing or misfiring nozzles.
One of the biggest benefits of this proprietary Mutoh print technology is that it offers predictable and repeatable output quality, therefore bringing an unprecedented level of ease of use to the printer operator. ValueJet printer users will be able to print ideal quality images fit for purpose every time, in the shortest possible time.
Dye Sublimation Transfer Papers
The ValueJet 1638WX prints on all typical dye sublimation transfer papers from 66 g/m² to 150 g/m². The printer is equipped with an automatic sheet-off function. Manual cutting is also possible using the dedicated cutting groove on the media guide.
The ValueJet 1638WX printer can handle 2” and 3” rolls.
The printer comes with a stand with integrated roll holders. Different motorised winding/unwinding systems are available for roll-to-roll production.
Explore new revenue opportunities such as high quality in-store textile decoration and displays, textile banners, pop-ups, sportswear, personalised home decoration, gadgets, shirts and many more.
ValueJet 1638WX – Technical Key Specifications
Print Technology – Drop-on-demand Micro Piezo Inkjet Technology
Print Head – 2 (staggered setup)
Nozzle Configuration – 180 nozzles x 8 lines / head
Drop Mass Range (pl) – 5.9 to 45.3
Head Heights – Low: 1.5 mm / Middle : 2.5 mm / High: 4.0 mm
Colour Set-up – 2×4 CMYK (speed set-up) or 8 colour (gamut set-up)
ValueJet 1638WX – Media Specifications
Media Width – 900 mm (36.8″) – 1625 mm (63,97”)
Max. Print Width – 1615 mm (63,58”)
Max. Media Thickness – 0.3 / 1.3 / 2.8 mm *
* : Max. media thickness is specified per head height
Media Measurements * – Ø 150 mm / 2” & 3” / 30 kg
* : Standard non-motorised roll-off system
ValueJet 1638WX – Performance
High Quality – Super Fine (1080 x 1080 dpi 9 p) – 11.0 m²/h
Quality (720 x 720 dpi 4 p) – 25.0 m²/h
Production (360 x 720 dpi 2 p) – 42.0 m²/h
Speed Production (360 x 360 dpi 2 p) – 50.0 m²/h
High Speed Production (360 x 360 1 p) – 65.0 m²/h
All indicated speeds are obtained in 2×4 colour set-up and using full print width.
ValueJet 1638WX – Ink Specifications
Ink Colours – CMYK
Ink Consumption Average – 8.5 ml / m²
UV durability – 3 to 6 months outdoor
Light fastness – ISO 105-B02(*) – C (5-6) / M (6-7) / Y (6-7) / K (6)
Washing fastness – ISO 105-C02(*) – C (4-5) / M (4-5) / Y (4-5) / K (4-5)
Perspiration fastness – ISO 105-E02(*) – C (4-5) / M (5) / Y (4-5) / K (4-5)
* : Score Ranges (min-max) : Light 1-8 / Washing 1-5 / Perspiration (1-5)
ValueJet 1638WX – Power Consumption
During Printing – < 200 W
In Stand‐by / Sleep Mode / Power Off – 38 W / 30 W / < 3.8 W
Power Supply – AC 100-120 V / AC 200-240 – 60/50 Hz
Noise (dB) – ± 69.8 (printing) / ± 60.5 (standby)
ValueJet 1638WX – Recommended Working Environment
Temperature – 22 °C – 30 °C with Δt: max. 2 °C/h
Humidity – 40% – 60 % (no condensation) with ΔRH: max. 5% RH/h
ValueJet 1638WX – Machine Measurements
Width x Depth x Height – 2698 x 885 x 1261 mm
Weight Desktop / Stand – 219 kg
