Mutoh ValueJet 1624WX
Product Overview
- Transfer sublimation printing up to 1625 mm (63.97”)
- Latest generation 8 channel 1440 nozzle piezo head
- Typical production speeds between 14 & 27.5 m²/h
- Mutoh water-based dye sublimation inks
- Ideal for production of soft signage, sportswear, gadgets, …
- Environmentally friendly printing – high level of operator safety
The compact Mutoh ValueJet 1624WX printer is ideal for every day sublimation printing. The printer is fit for both startup and established businesses wanting to extend their product portfolio.
Mutoh ValueJet 1624WX prints on typical 95 g/m² – 100 g/m² dye sublimation transfer papers, making transfer onto all possible flexible and rigid polyester materials possible.
1440 dpi Piezo Print Head
The Mutoh ValueJet 1624WX printer incorporates a latest generation piezo drop-on-demand variable drop print head. This 1440-nozzle head (8 lines of 180 nozzles) incorporates four colour sections, each divided in two nozzle rows with 360 nozzles per colour. As all colour sections are united in one head, there is no need for time-consuming head-to-head calibration procedures.
Stunning Performance
The Mutoh ValueJet VJ-1624WX printer offers you a wide range of print modes and speeds. The overview below lists the most popular ones with which impeccable printing quality can be obtained.
- High Quality – 540×720 dpi: 9.0 m²/h
- Production – 360×720 dpi: 20.5 m²/h
- Speed Production – 360×360 dpi: 27.5 m²/h
Maximize your Profit with Mutoh Intelligent Interweaving (i²) Print Technology
The Mutoh ValueJet 1624WX incorporates Mutoh’s award-winning Intelligent Interweaving (i²) print technology, enabling a drastic reduction or even total elimination of the typical difficulties inherent to conventional digital inkjet printing, such as horizontal banding, step mismatch banding and the visible effects of missing or misfiring nozzles.
One of the biggest benefits of this proprietary Mutoh print technology is that it offers predictable and repeatable output quality, therefore bringing an unprecedented level of user comfort to the printer operator. ValueJet printer users will be able to print ideal quality images fit for purpose every time, in the shortest possible time.
Media Handling
The Mutoh ValueJet 1624WX printer can handle 2” and 3” rolls. The printer comes with a stand with integrated roll holders. Different winding/unwinding systems are available for roll-to-roll production.
Explore new revenue opportunities such as high quality in-store textile decoration and displays, textile banners, pop-ups, sportswear, personalised home decoration, gadgets, shirts and many more.
ValueJet 1624WX – Technical Key Specifications
Print Technology – Drop-on-demand Micro Piezo Inkjet Technology
Print Head – 1
Nozzle Configuration – 180 nozzles x 8 lines – 360 nozzles per colour
Drop Mass Range (pl) – 3.3 to 34.1
Head Heights – Low: 1.5 mm / Middle: 2.5 mm / High: 4.0 mm
ValueJet 1624WX – Media Specifications
Max. Media Width – 1625 mm (63,97”)
Max. Print Width – 1615 mm (63,58”)
Max. Media Thickness – 0.3 mm / 1.3 mm / 2.8 mm *
* : Max. media thickness is specified per head height
Media Measurements * – Ø 150 mm / 2” & 3” / 30 kg
* : Standard non-motorised roll-off system
ValueJet 1624WX – Performance
High Quality (540 x 720) – 9.0 m²/h
Quality (720 x 720) – 14.0 m²/h
Production (360 x 720) – 20.5 m²/h
Speed Production (360 x 360) – 27.5 m²/h
Billboard (360 x 360) – 38.0 m²/h
ValueJet 1624WX – Ink Specifications
Ink Colours – CMYK
Ink Consumption – 8,5 ml / m²
UV durability – without lamination – 3 to 6 months outdoor
ValueJet 1624WX – Power Consumption
During Printing – < 210 W
In Stand-by – 38 W
Power Supply – AC 100-120 V / AC 200-240 – 60/50 Hz
ValueJet 1624WX – Recommended Working Environment
Temperature – 20 °C – 30 °C with Δt: max. 2 °C/h
Humidity – 40 % – 60 % (no condensation) with ΔRH: max. 5 % RH/h
ValueJet 1624WX – Machine Measurements
Width x Depth x Height – 2698 x 885 x 1261 mm
Weight Desktop / Stand – 160 kg
