Mutoh ValueJet 1638UH

Product Overview

  • 1625 mm (63.97”) wide LED UV technology
  • C, M, Y, K LED UV inks – Optional White & Varnish for a luxurious or specialty finish
  • Output immediately dry & ready for use or second stage treatment
  • Low energy consumption – Low heat generation, ideal for heat sensitive media
  • Output is VOC free, no outgassing of prints – No Ozone in the production area  – No Mercury – No Lead
  • Automatic media thickness measurement & head height adjustment
  • Mutoh intelligent interweaving inside with dedicated “UV-weaving”

The ValueJet VJ-1638UH is Mutoh’s first ever dual head LED UV printer delivering increased print & cure performance. 162.5 cm (64”) wide, the VJ-1638UH is all about versatility; it is the ideal tool to expand your business with a wide range of commercial print applications. The printer accommodates 1625 mm (63.97”) roll media up to 30 kg as well as rigid boards up to 1625 mm x 1200 mm (63,97” x 47,24”) up to 15 mm thick and up to 15 kg. For automatic roll up of prints, the VJ-1638UH can be equipped with a 30 kg or 100 kg motorised take-up system.

This printer will enable you to maximize your creativity! Next to CMYK, the VJ-1638UH also can be set-up with varnish and white to handle transparent or non-white substrates without losing colour power or to create special print effects and multi-layer printing for prints with high added value. Both flex and rigid inks are available.

The Printer’s Heart Beats Quality

A staggered dual head setup with latest generation variable drop piezo print heads is at the heart of the ValueJet 1638UH’s stunning performance. Each 1440-nozzle head (8 lines of 180 nozzles) incorporates four colour sections, divided in two nozzle rows with 360 nozzles per colour. The integrated print heads are capable of producing ink drops ranging from 3.8 pl to 28 pl.

LED UV Inks for Ultra-sharp, Safe & Ready to Use Prints

Mutoh’s LED UV inks are zero VOC liquids which do not contain hazardous air pollutants (non-HAP). Both flex and rigid inks are available.

Two powerful long-life (14.250 hours) LED UV lamps are Mercury and Lead free and they ensure Ozone free, safe and ultra-sharp prints, which are ready to be used or laminated immediately after printing. LED lamps don’t create heat towards the media, making the technology extremely well suited for handling heat sensitive media as opposed to “classic” UV or water-based resin ink technologies generating huge amounts of heat or relying on high temperatures to dry the ink.

Roll & Rigid Media

With front & rear roller tables, the printer accommodates rigid materials up to 15 mm thickness with a maximum weight of 15 kg. Media thickness is measured electronically and head height is adjusted automatically. Media loading is quick and easy with the media alignment option. For motorised roll up of roll media, the ValueJet 1638UH can be equipped with a tension winder 30 system taking media rolls up to 30 kg, or alternatively with a motorised roll off/take up system for rolls up to 100 kg. Conversion from rigid to roll mode or vice versa only takes a minute.

Maximize your Profit with Mutoh Intelligent Interweaving (i²) Print Technology

The ValueJet 1638UH incorporates Mutoh’s award-winning Intelligent Interweaving (i²) print technology, enabling a drastic reduction or even total elimination of the typical difficulties inherent to conventional digital UV inkjet printing. Dedicated i² print effects for the Mutoh LED UV inks have been engineered, ensuring a drastic reduction of the curing structure in the ink layer and gloss banding suppression.

One of the biggest benefits of this proprietary Mutoh print technology is that it offers predictable and repeatable output quality, therefore bringing an unprecedented level of user comfort to the printer operator. ValueJet printer users will be able to print ideal quality images fit for purpose every time, in the shortest possible time.

Wide Choice of Media

The ValueJet VJ-1638UH LED-UV printer will deliver high quality prints on a huge variety of roll and rigid media, including non-conventional media types, such as ABS, Aluminium board, Cardboard, Fluted & corrugated boards, Glass, heat sensitive flex media like Polyolefin-based (PVC-Free) self-adhesive films, Non-woven, PC, PE, PET, PES, PMMA (acrylic), PP, PS, PVC *.

* : Ink adhesion will vary among media type and brand. Some media may require a primer or may benefit from corona treatment. Individual testing is required in function of your choice of material, brand and specific application.

The ValueJet VJ-1638UH will produce high quality graphics for short viewing distances such as trade show graphics, POP & retail signage, backlit banners, individualised wallpaper & interior decoration, small lot packaging prototypes, banners, posters, etc.

ValueJet 1638UH apps



ValueJet 1638UH – Technical Key Specifications

Print Technology – Drop-on-demand Micro Piezo Inkjet Technology
Print Head – 2 (staggered setup)
Nozzle Configuration – 180 nozzles x 8 lines (each head)
Drop Mass Range (pl) – 3.8 to 28
Head Heights – Automatic*
* : Media thickness is measured electronically and head height is automatically adjusted
LED UV lamp life – 14.250 hours

ValueJet 1638UH – Media Specifications

Min./Max. Media Width – 182 mm (7.17″) / 1625 mm (63,97”)
Max. Print Width – 1615 mm (63,58”)
Max. Media Thickness – 15 mm
Media Measurements * – Ø 150 mm / 2” & 3” / 30 kg
* : Standard non-motorised roll-off system
Ink Drying System – 2 Long life LED UV curing lamp

ValueJet 1638UH – Rigid Media Specifications

Min./Max. Media Width – 182 mm (7.17″) / 1625 mm (63,97”)
Max. Print Width – 1615 mm (63,58”)
Max. Media Length – 200 (7.87″) – 1200 mm (47.24″)
Max. Media Thickness – 15 mm
Max. Media Weight – 15 kg
Ink Drying System – 2 Long life LED UV curing lamp

ValueJet 1638UH – Performance

ValueJet 1638UH performance

ValueJet 1638UH – Ink Specifications

Ink Type – LED UV inks – Rigid and Flexible types
Ink Colours / Volume – CMYK + Varnish – 220 ml cassette / 800 ml bag*
                                                White : 220 ml cassette / 500 ml bag*
* : 800 ml / 500 ml pack requires optional adapter
Ink Setup – CMYK (CCMMYYKK)
CMYK + White + Varnish (CMYK+2xWh+2xVa)
Compatibility – ABS, Aluminium board, Cardboard, Fluted &corruga- ted boards, Glass, heat sensitive flex media like Polyolefin-based (PVC-Free) self-adhesive films, Non-woven, PC, PE, PET, PES, PMMA (acrylic), PP, PS, PVC *
* : Ink adhesion will vary among media type and brand. Some media may require a primer or may benefit from corona treatment. Individual testing is required in function of your choice of material, brand and specific application.

ValueJet 1638UH – Power Consumption

During Printing – < 700 Watt
In Stand-by / Sleep – < 55 W / < 25 W
Power Supply – AC 100-120 V / AC 200-240 – 60/50 Hz – ≤ 4.0 A / ≤ 2.0 A

ValueJet 1638UH – Recommended Working Environment

Temperature – 20 °C – 32 °C with Δt: max. 2 °C/h
Humidity – 40% – 60 % (no condensation) with ΔRH: max. 5% RH/h

ValueJet 1638UH – Machine Measurements

Width x Depth x Height – 2983 x 818 x 1261 mm (roll)  &  2983 x 2730 x 1261 mm (rigid)
Weight – 197 kg (printer + stand)
